FLIGHT HEAD ADAPTER

Digital and analog integration for Filmotechnic Flight Heads

Through continuous development and testing, cmotion now offer integration for both digital and analog Filmotechnic Flight Heads.

cmotion`s Flight Head solutions

lens control through Filmotechnic Flight Head Control Panel



Through continuous development and testing, cmotion now offer integration for both digital and analog Filmotechnic Flight Heads. Whilst the digital solution passes focus and zoom control direct from the Flight Head control panel to the cvolution camin, the analog solution passes zoom control from the Flight Head control panel through our new Flight Head Adapter to either a cmotion or ARRI hand unit and then uses wireless communication to the  camin, ARRI UMC-4 or ARRI ALEXA Plus / Mini .




Digital integration for Flight Head 6 In this configuration, the camin is mounted on or near the camera and connected directly to the Flight Head’s digital interface. cforce, ARRI or Hedén motors can be used and once calibrated, focus and zoom are automatically assigned to the Flight Head’s control panel. With an additional motor, it is possible to control iris using a wireless cvolution hand unit (camin firmware 3.11.28 or higher required).

Analog Integration

In this configuration, an analog Flight Head control panel can be connected to a cmotion or ARRI wireless hand unit through the new cmotion Flight Head Adapter. This adapter allows the operator to control the zoom axis from the control panel and use the wireless connection between a cmotion or ARRI hand unit and motor box. Once connected and calibrated, zoom control is automatically assigned to the Flight Head control panel. Focus and iris motors can also be connected to the camin / UMC-4 / ALEXA Plus / Mini and controlled through the corresponding cmotion (cvolution / compact LCS) or ARRI WCU-4 hand unit.



Odoo text and image block

How it works?

The Flight Head Adapter connects either the  cvolution hand unit, compact LCS hand unit  or ARRI`s WCU-4  to the  Flight Head control panel  via the  FHC-1 cable . The analog zoom signal of the Flight Head control panel is converted into a digital signal and sent to the hand unit. The hand unit sends all signals together (focus and iris of the hand unit and the zoom signal of the Flight Head control panel) to the receiving unit (either cvolution camin, compact LCS camin, ALEXA Plus, ALEXA Mini or UMC-4). In this configuration, the Flight Head operator can control the zoom motor, while the 1.AC has control over iris and focus.
